型號 Model | 攻牙能力范圍(S45C) Tooth Attack Capability Range (S45C) | 額定功率(W) Rated Power(W) | 攻牙轉速范圍(r/min) Tapping speed range r/min | 工作半徑(mm) Working radius mm | 工作電源 Working power supply | 基礎配置 basic configuration |
M3-M16 | M3-M16 | 600 | 0-312無級調速 0-312 stepless speed regulation | 1100 | 交流220V±15% AC 220V ± 15% | 關節臂支架一套(One set of articulated arm bracket) 伺服電機一套(One set of servo motor)行星減速機一套(One set of planetary reducer) 對應型號夾頭整套(Complete set of corresponding model collets) |
M4-M24 | M4-M24/M4-M20鋼steel | 1200 | 0-550無級調速 0-550 stepless speed regulation | 1200 |
M6-M30 | M6-M33/M6-M30鋼steel | 1200 | 0-200無級調速 0-200 stepless speed regulation | 1200 |
M6-M36 | M6-M36/M6-M33鋼steel | 1200 | 0-156無級調速 0-156 stepless speed regulation | 1300 |
M12-M48 | M12-M52/M12-M48鋼steel | 1200 | 50-200無級調速 50-200 stepless speed regulation | 1300 |
